Deep Learning Guide

Posted Nov 22, 2025

By eya_garci 42 min read

Introduction

What is a Neural Network?

A neural network is a system that learns from examples, inspired by the human brain. It is composed of layers of neurons that progressively transform data.

Basic structure:

Input layer: receives data (images, text, numbers)
Hidden layers: extract increasingly complex features
Output layer: produces the final prediction

How a Network Learns

Learning happens in 4 repeated steps:

Forward Propagation: data passes through the network
Error calculation: we measure how wrong the prediction is
Backward Propagation: we calculate how to adjust each neuron
Update: we modify the weights to reduce error

This cycle repeats thousands of times until the model becomes accurate.

The Two Major Problems

Underfitting

The model is too simple
Doesn’t capture patterns in the data
Poor performance everywhere (train AND validation)
Solution: make the model more complex

Overfitting

The model memorizes instead of understanding
Excellent performance on training data
Poor performance on new data
Solution: regularization, more data

Sequence Models - Architecture and Usage

What is a Sequence Model?

Beginner definition: A Sequence Model is a special type of neural network that understands that the order of data is important. Unlike classic networks that look at each data point in isolation, Sequence Models “remember” what they’ve seen before.

Why is order important?

Let’s take simple examples:

Example 1 - Text:

“The dog eats the apple” ✅ (makes sense)
“Apple the eats dog the” ❌ (same words, but no sense)

→ Word order completely changes the meaning!

Example 2 - Video:

Image 1: person standing
Image 2: person bent
Image 3: person on ground
→ Sequence = someone falling

If we shuffle the order: person on ground → standing → bent (weird!)

Example 3 - Weather:

Day 1: 20°C
Day 2: 22°C
Day 3: 24°C
→ Trend: it’s warming up

To predict Day 4, you need to know this trend (previous days).

Types of data for Sequence Models

Sequence Models handle data that has an order or temporal dependency:

1. Text:

Words follow in a specific order
“I love you” ≠ “you love I”
Example: translation, text generation, chatbots

2. Time series:

Data that evolves over time
Stock prices, temperature, sales numbers
The past influences the future

3. Audio:

Sounds that follow each other
Speech recognition (Siri, Alexa)
A word depends on previous sounds

4. Video:

Sequence of images
Action detection (someone running, jumping)
A single image is not enough

Fundamental difference

Classic networks (no memory):

Input 1 → Network → Output 1
Input 2 → Network → Output 2
Input 3 → Network → Output 3

→ Each prediction is independent → The network doesn’t remember Input 1 when processing Input 2

Sequence Models (with memory):

Input 1 → Network → Output 1
            ↓ (memory)
Input 2 → Network → Output 2
            ↓ (updated memory)
Input 3 → Network → Output 3

→ Each prediction uses history → The network “remembers” what it saw before

Types of Sequence Models

1. RNN (Recurrent Neural Networks)

Simple definition: RNN is the most basic Sequence Model. It reads data one by one (like reading a book word by word) and maintains a “memory” of what it saw before.

How it works - Concrete example:

Imagine you’re reading the sentence: “The cat eats the mouse”

Step 1: Reads “The”

Memory: [“The”]
Understands: a definite article

Step 2: Reads “cat” + remembers “The”

Memory: [“The”, “cat”]
Understands: we’re talking about a specific cat

Step 3: Reads “eats” + remembers “The cat”

Memory: [“The”, “cat”, “eats”]
Understands: the cat is performing an action

Step 4: Reads “the” + remembers the context

Memory: [“The”, “cat”, “eats”, “the”]
Understands: a second thing will be mentioned

Step 5: Reads “mouse” + all the context

Complete memory: [“The”, “cat”, “eats”, “the”, “mouse”]
Understands: the cat eats the mouse (complete meaning!)

The secret of RNN: At each step, it combines:

The new word it just read
Its memory of everything it read before

Detailed analogy: It’s like reading a detective novel:

Page 1: you discover the crime
Page 50: you discover a suspect, but you remember the crime
Page 100: a new clue, but you remember everything you’ve read
Final page: you understand the whole story thanks to your memory

Strengths:

Simple to understand
Can process sequences of any length
Shares knowledge across all steps

Weaknesses:

Forgets on long sequences (loses memory)
Difficulty connecting distant information in text
Slow to train (must process sequentially)

When to use it:

Short sequences (less than 50 elements)
Simple tasks
Predicting the next word/number in a short sequence

2. LSTM (Long Short-Term Memory)

Simple definition: LSTM is a much smarter version of RNN. Instead of simple memory, it has a sophisticated system of “gates” that decide what to keep, what to forget, and what to use.

The problem with simple RNN: Imagine reading a 300-page book. By page 300, you’ve forgotten the details from page 1!

→ RNN has the same problem: after 50-100 elements, it forgets the beginning.

How LSTM solves this problem:

LSTM has 3 “smart gates” (like guards that control information):

1. Forget Gate:

Question: "Is this information still useful?"

Example: "Mary loves cats. She also adores dogs. Mary..."
→ KEEP "Mary" (important for the rest)
→ FORGET "loves cats" (less important now)

2. Input Gate:

Question: "Is this new information important to remember?"

Example: "The president resigned yesterday."
→ VERY important! We keep it in memory

Example: "It was nice weather."
→ Less important, we can forget it

3. Output Gate:

Question: "What information do I need RIGHT NOW?"

Example: "Mary and Peter arrived. Mary said..."
→ At this moment, we need to remember that Mary is a person
→ We extract this information from memory

Detailed analogy with a library:

Imagine your brain as a library with a librarian (the LSTM):

Forget Gate:

Librarian: “This book about dinosaurs hasn’t been used in 5 years”
Action: Remove it from the main shelves

Input Gate:

Librarian: “This new book about AI is in high demand”
Action: Put it prominently on the main shelf

Output Gate:

You: “I need information about Python”
Librarian: Searches in memory and pulls out the right book

Concrete example - Translation:

English: "The cat that was sitting on the mat is black"
French: "Le chat qui était assis sur le tapis est noir"

Step 1: Reads "The cat"
→ KEEP in memory: "cat" (main subject)

Step 2-6: Reads "that was sitting on the mat"
→ UNDERSTANDS: description of the cat
→ KEEPS: the information that it's still the same cat

Step 7: Reads "is black"
→ USES memory: remembers that "black" describes "the cat" from the beginning
→ Correctly translates: "Le chat... est noir" (gender agreement)

Why it’s better than RNN:

RNN: forgets “The cat” after 5-10 words
LSTM: remembers “The cat” even after 50-100 words

Strengths:

Long-term memory: remembers over hundreds of elements
Solves RNN’s forgetting problem
Automatically learns what is important

Weaknesses:

More complex than RNN
Slower to train
Requires more data

When to use it:

Long texts (articles, books)
Time series with long-term trends
Sentiment analysis over multiple sentences
Financial forecasting
Speech recognition

3. GRU (Gated Recurrent Unit)

Simple definition: GRU is a simplified and faster version of LSTM. Instead of 3 gates, it has only 2, but it works almost as well.

The idea behind GRU: The creators of GRU said: “LSTM works well, but it’s complicated. Can we make it simpler?”

Result: Merge some of LSTM’s gates

The 2 gates of GRU:

1. Update Gate:

Question: "How much old information to keep VS new to add?"

Example: "Peter likes soccer. Now, he prefers basketball."

→ Old info: "Peter likes soccer" (less important)
→ New info: "Peter prefers basketball" (more important)
→ The gate decides: keep 20% old, 80% new

2. Reset Gate:

Question: "Should I completely ignore the past for this new info?"

Example: "Mary talks about her cat. Subject change: the weather is nice."

→ The gate decides: RESET! New subject, we start from zero

Comparison LSTM vs GRU:

LSTM (3 gates):
├─ Forget gate: what to erase?
├─ Input gate: what to add?
└─ Output gate: what to use?
   → More powerful but slower

GRU (2 gates):
├─ Update gate: how much old/new?
└─ Reset gate: start from zero?
   → Simpler and faster

Analogy - Updating a CV:

LSTM (3 decisions):

What to remove from the old CV? (Forget gate)
What to add new? (Input gate)
What to show the recruiter? (Output gate)

GRU (2 decisions):

How much to keep old VS new? (Update gate)
Redo the CV completely? (Reset gate)

When to choose GRU over LSTM:

✅ Use GRU if:

You have a not huge dataset (< 100k examples)
You want to train faster
You have memory constraints
You’re a beginner (simpler to understand)

✅ Use LSTM if:

You have a lot of data (> 1M)
The task is very complex
You have time and resources
You want to extract maximum performance

Strengths:

Faster than LSTM
Fewer parameters = less risk of overfitting
Performance often similar to LSTM

Weaknesses:

Slightly less powerful than LSTM on very complex tasks

When to use it:

Alternative to LSTM when resources are limited
Medium-sized dataset
Need for training speed

4. Transformers

Simple definition: Transformer is a revolution in Sequence Models. Instead of reading word by word (RNN, LSTM), it looks at THE WHOLE sentence at once and decides which words are important to each other.

The problem with RNN/LSTM:

Imagine reading this sentence word by word:

"The cat that I saw yesterday in my neighbor's garden eats a mouse"

With RNN/LSTM:

Reads “The”
Reads “cat” (remembers “The”)
Reads “that”
Reads “I”…
…(many words)…
Reads “eats”

→ Problem: when we get to “eats”, we’ve almost forgotten “The cat”! → It’s slow: we must read in order, word by word

With Transformer:

Looks at ALL words at once
Immediately identifies: “The cat” is the subject, “eats” is the action
Instantly connects “The cat” and “eats” even if they’re far apart

The Attention Mechanism Explained Simply

Analogy - Classroom:

Imagine a class with 10 students. The teacher asks a question:

Without attention (RNN):

The teacher asks each student one by one
Each student answers without listening to others
Slow and sequential

With attention (Transformer):

The teacher asks the question to EVERYONE at once
Each student can look at and listen to ALL the others
Student 5 can say “I agree with student 2”
Fast and parallel

Concrete Example - Translation

French sentence: “Le chat noir mange la souris grise” English translation: “The black cat eats the grey mouse”

Transformer pays attention to:

To translate “black”:

Looks at: "noir"
Pays attention to: "chat" (to know that "noir" describes the cat)
Translation: places "black" after "cat" → "black cat"

To translate “grey”:

Looks at: "grise"
Pays attention to: "souris" (to know that "grise" describes the mouse)
Translation: places "grey" after "mouse" → "grey mouse"

Attention matrix (who looks at who):

           Le  chat  noir  eats  the  mouse grey
Le        [++   +     -     -     -    -     -  ]
chat      [ +  ++     +     +     -    -     -  ]
noir      [ -   ++   ++     -     -    -     -  ]
eats      [ +   +     -    ++     -    +     -  ]
the       [ -   -     -     +    ++    +     -  ]
mouse     [ -   -     -     +     +   ++     +  ]
grey      [ -   -     -     -     -   ++    ++  ]

++ = pays a lot of attention

= pays a little attention
= ignores

Reading:

“noir” pays a lot of attention to “chat” (it describes it)
“grise” pays a lot of attention to “souris” (it describes it)
“mange” pays attention to “chat” (subject) and “souris” (object)

Why it’s revolutionary:

1. Parallelization:

RNN/LSTM: Word1 → Word2 → Word3 → Word4 (sequential, slow)
Transformer: All words processed AT THE SAME TIME (parallel, fast)

2. No distance limit:

Sentence: "The man that I saw yesterday who wore a red hat eats"

RNN/LSTM: difficult to connect "The man" and "eats" (too far)
Transformer: easily connects "The man" and "eats" (direct attention)

3. Multi-head Attention (multiple heads):

The Transformer doesn’t pay attention just ONCE, it does it SEVERAL times in parallel:

Head 1: looks at grammar (subject, verb, object)
Head 2: looks at adjectives and their nouns
Head 3: looks at temporal relations
Head 4: looks at general context
...

It’s like having 8-12 experts analyzing the sentence differently, then combining their opinions.

Famous applications of Transformers:

GPT (Generative Pre-trained Transformer):

ChatGPT, GPT-4
Generates text like a human

BERT (Bidirectional Encoder Representations from Transformers):

Google Search
Understands search context

T5, BART:

Translation
Text summarization

DALL-E, Stable Diffusion:

Image generation from text
Use adapted Transformers

Strengths:

Parallelization: ultra-fast training (all words at once)
Easily captures relationships between distant words
Architecture used in GPT, BERT, ChatGPT
Best performance on almost all tasks

Weaknesses:

Consumes a lot of memory for very long sequences
Requires enormous data and computing power
More complex to understand and implement

When to use it:

Machine translation (Google Translate, DeepL)
Chatbots and assistants (ChatGPT, Claude)
Long document analysis
Text generation
Automatic Question-Answering

Quick Comparison of Sequence Models

Model	Memory	Speed	Complexity	Best for
RNN	Short	Slow	Simple	Short sequences
LSTM	Long	Slow	Medium	Long sequences
GRU	Long	Medium	Medium	Speed/performance compromise
Transformer	Very long	Fast	High	Modern NLP, large datasets

Activation Functions

What is an Activation Function?

An activation function decides whether a neuron should “activate” or not. It transforms the signal that the neuron receives.

Why it’s important: Without activation, the network would just be a series of multiplications (linear). Activations add non-linearity, allowing learning of complex patterns.

Main Activation Functions

ReLU (Rectified Linear Unit)

Simple definition: ReLU is like a filter that only lets through positive values. It’s the most used activation function in deep learning.

Principle:

If the signal is positive → keep it as is
If the signal is negative → set it to zero

Advantages:

Extremely fast to compute
Works well in 90% of cases
Simple and effective

Disadvantages:

“Dead neurons”: some neurons can get stuck at zero permanently

When to use:

Default choice for hidden layers
Suitable for almost all types of networks

Example of use:

Input signal: [2, -1, 0.5, -3]
After ReLU: [2, 0, 0.5, 0]

Leaky ReLU

Simple definition: Improved version of ReLU that lets through a very small value even for negative numbers, preventing neurons from “dying”.

Principle:

If positive signal → keep
If negative signal → keep a small value (instead of complete zero)

Advantages:

Avoids dead neurons
Slightly better than ReLU in some cases

When to use:

If you notice many stuck neurons with ReLU
Safe alternative to ReLU

Sigmoid

Simple definition: Sigmoid transforms any number into a value between 0 and 1, which is perfect for representing a probability (e.g., 0.8 = 80% chance).

Principle: Transforms any value into a number between 0 and 1

Advantages:

Interpretable as a probability
Output between 0 and 1 (perfect for “yes/no”)

Disadvantages:

In deep networks, the gradient becomes very weak
Slows down learning

When to use:

Output layer for binary classification (true/false, spam/not-spam)
DO NOT use in hidden layers

Example:

Very positive signal (5) → close to 1 (very confident “YES”)
Signal close to 0 → around 0.5 (uncertain)
Very negative signal (-5) → close to 0 (very confident “NO”)

Tanh

Simple definition: Like Sigmoid but with values between -1 and 1 instead of 0 and 1. It’s better for internal network layers because it’s centered on zero.

Principle: Transforms any value into a number between -1 and 1

Advantages:

Centered on zero (better than sigmoid for internal layers)
Output between -1 and 1

Disadvantages:

Same weak gradient problem as sigmoid

When to use:

Some RNN and LSTM (in the gates)
Alternative to sigmoid, but less common now

Softmax

Simple definition: Softmax takes multiple scores and transforms them into probabilities that total 100%. Useful when you need to choose ONE option among several (cat OR dog OR bird).

Principle: Transforms a vector of numbers into probabilities that sum to 1

How it works:

Takes multiple values
Transforms them into probabilities
The largest value gets the largest probability

When to use:

Output layer for multi-class classification
When you want to choose among multiple options

Concrete example:

Input: [2.0, 1.0, 0.1]  (raw scores)
Softmax: [0.66, 0.24, 0.10]  (probabilities)

Interpretation:
- 66% chance it's class 1 (cat)
- 24% chance it's class 2 (dog)
- 10% chance it's class 3 (bird)

GELU (for Transformers)

Simple definition: GELU is a modern activation specially designed for Transformers (like ChatGPT). It’s a more sophisticated version of ReLU.

Principle: Smoother and more complex version of ReLU

When to use:

Modern Transformers (BERT, GPT)
State-of-the-art NLP
Better performance than ReLU on these architectures

Swish

Simple definition: Swish is an activation automatically discovered by Google’s artificial intelligence. It works particularly well for image recognition.

Principle: Smooth curve that works well in practice

When to use:

Modern alternative to ReLU
Computer vision
Automatically found by Google

Summary Table of Activation Functions

Function	Output Range	Main Usage	Speed	Notes
ReLU	0 to ∞	Hidden layers	⚡⚡⚡	Default choice
Leaky ReLU	-∞ to ∞	Hidden layers	⚡⚡⚡	Alternative to ReLU
Sigmoid	0 to 1	Binary output	⚡⚡	Only in output
Tanh	-1 to 1	RNN/LSTM	⚡⚡	Less common
Softmax	0 to 1 (sum=1)	Multi-class output	⚡	Classification
GELU	-∞ to ∞	Transformers	⚡	Modern NLP
Swish	-∞ to ∞	Vision	⚡⚡	Recent alternative

Quick selection guide:

Hidden layers? → ReLU
Binary classification in output? → Sigmoid
Multi-class classification in output? → Softmax
Transformers? → GELU
Problems with ReLU? → Leaky ReLU

Hyperparameters

What is a Hyperparameter?

Hyperparameters are settings that you choose before training. The model doesn’t learn them automatically - it’s up to you to define them.

Important difference:

Parameters: the model learns them (weights of connections between neurons)
Hyperparameters: you choose them (number of layers, learning rate…)

Network Architecture

Number of Layers

Impact:

Few layers (1-2): simple model, learns basic patterns
Many layers (10-100): complex model, learns abstractions

How to choose:

Simple problem (XOR, addition) → 1-2 layers
Images (classification) → 20-100 layers
Complex NLP (translation) → 12-96 layers

Practical rule: Start small (2-3 layers), increase if performance is insufficient.

Number of Neurons per Layer

Impact:

Few neurons (32-64): fast but limited
Many neurons (512-2048): powerful but slow

Common patterns:

Funnel architecture (recommended):

512 → 256 → 128 → 64

Progressively reduces, extracts increasingly abstract features

Constant architecture:

256 → 256 → 256

Maintains the same capacity at each level

How to choose:

Small dataset → fewer neurons (avoids overfitting)
Large dataset → more neurons (can learn more)
Start with 128-256, adjust based on results

Training Hyperparameters

Learning Rate - THE MOST IMPORTANT

What is it: Controls the step size that the model takes to improve.

Analogy: Descending a mountain in fog:

High learning rate: big jumps → risk of jumping over the minimum
Low learning rate: small steps → arrives slowly but surely
Optimal learning rate: balance between speed and precision

Typical values:

0.1: very high, risk of divergence
0.01: high, for SGD
0.001: standard for Adam (recommended starting point)
0.0001: low, for fine-tuning
0.00001: very low, very slow convergence

Symptoms and solutions:

Too high:

Loss oscillates violently
Loss becomes NaN (Not a Number)
The model never improves
Solution: divide by 10

Too low:

Loss decreases very slowly
Training takes hours/days
Stuck in a local minimum
Solution: multiply by 2-5

Batch Size

What is it: Number of examples processed simultaneously before updating weights.

Impact:

Small batch (8-32):

✅ Better generalization
✅ Less memory required
❌ Slower training
❌ Noisy gradient (less stable)

Large batch (128-512):

✅ Faster training
✅ More stable gradient
✅ Better GPU utilization
❌ Requires a lot of memory
❌ Risk of poorer generalization

How to choose:

8GB GPU: batch 32-64
16GB GPU: batch 64-128
32GB+ GPU: batch 128-512

Advice: use the largest batch your GPU can support.

Number of Epochs

What is it: One epoch = one complete pass over all training data.

How to choose:

Small dataset (<10k examples): 100-500 epochs
Medium dataset (10k-100k): 50-200 epochs
Large dataset (>1M): 10-50 epochs

Important: use early stopping which automatically stops when the model stagnates (see Regularization section).

Optimizers - How the Model Learns

SGD (Stochastic Gradient Descent)

Simple definition: SGD is the most basic learning algorithm. It adjusts the network’s weights little by little by following the direction that reduces error. It’s like descending a hill step by step.

Principle: The basic algorithm - descends in the direction that reduces error.

Advantages:

Simple to understand
Well-studied theoretically

Disadvantages:

Slow to converge
Very sensitive to learning rate

When to use it:

Rarely in practice (mainly for teaching)

SGD + Momentum

Simple definition: Momentum adds inertia to SGD, like a rolling ball that picks up speed. This allows faster learning and avoids getting stuck.

Principle: Accumulates directions of previous steps (like a rolling ball picking up speed).

Advantages:

Converges faster than simple SGD
Fewer oscillations
Can escape certain local minima

When to use it:

Computer vision (some famous models use it)
When you have time to properly tune the learning rate
Searching for the best possible generalization

Adam (Adaptive Moment Estimation) - THE DEFAULT CHOICE

Simple definition: Adam is the most popular and easiest to use optimizer. It automatically adjusts the learning speed for each network parameter, making it very effective without too much configuration.

Principle: Automatically adapts the learning rate for each parameter. Combines several smart techniques.

Advantages:

Works well “out of the box” with little tuning
Not very sensitive to initial learning rate choice
Converges quickly
Used in 90% of cases

Disadvantages:

Can sometimes generalize less well than SGD+Momentum

When to use it:

Default choice to start
NLP, Transformers
When you want quick results
Most situations

Recommended configuration:

Learning rate: 0.001 (standard value)

AdamW (Improved Adam)

Simple definition: AdamW is Adam with better regularization management. It has become the standard for training large language models like GPT and BERT.

Principle: Improved version of Adam that handles regularization better.

When to use it:

Modern Transformers (BERT, GPT)
State-of-the-art NLP
When Adam + L2 regularization doesn’t work well

RMSprop

Simple definition: RMSprop is an optimizer that adapts well to data that changes over time. It’s particularly effective for recurrent networks (RNN, LSTM).

Principle: Adapts learning rate, good for certain architectures.

When to use it:

RNN and LSTM (very effective)
Non-stationary data

Optimizer Comparison Table

Optimizer	Adaptive	Speed	Ease of use	Best for
SGD	❌	Slow	Difficult	Baseline
SGD + Momentum	❌	Medium	Difficult	Vision (ResNet)
Adam	✅	Fast	Easy	Everything (default)
AdamW	✅	Fast	Easy	Transformers
RMSprop	✅	Fast	Easy	RNN/LSTM

Selection guide:

Don’t know what to choose? → Adam (lr=0.001)
RNN/LSTM? → RMSprop
Transformers? → AdamW
Vision + time to tune? → SGD + Momentum
Everything else? → Adam

Loss Functions - Measuring Error

What is a Loss Function?

The loss function measures how wrong the model is. It’s what the model tries to minimize during training.

Analogy: A teacher grading a test - the loss is the number of points lost.

Loss Functions for Regression

Mean Squared Error (MSE)

Simple definition: MSE measures error by calculating the square of the difference between prediction and reality. The larger the error, the more severe the penalty (exponential effect).

Description: It’s like a very strict teacher who punishes 4 times harder for an error that’s 2 times larger.

Principle: Calculates the square of the difference between prediction and truth, then takes the average.

Characteristics:

Penalizes very hard large errors
Error of 10 → penalty of 100
Error of 20 → penalty of 400 (2× error = 4× penalty!)

Advantages:

Easy to optimize
Heavily penalizes large errors

Disadvantages:

Very sensitive to outliers
A single large error can dominate training

When to use:

Standard regression (price, temperature)
When large errors are really serious

Mean Absolute Error (MAE)

Simple definition: MAE measures error by simply taking the absolute difference between prediction and reality. It’s a fairer and easier to understand measure.

Description: It’s like a fair teacher who punishes proportionally: error 2 times larger = punishment 2 times larger.

Principle: Calculates the absolute value of the difference, then takes the average.

Characteristics:

Penalty proportional to error
Error of 10 → penalty of 10
Error of 20 → penalty of 20 (2× error = 2× penalty)

Advantages:

Robust to outliers
Easy to interpret (same unit as predicted variable)

Disadvantages:

Treats all errors the same way

When to use:

Presence of outliers in data
You want to treat small and large errors fairly
Interpretability is important

Huber Loss - The Compromise

Simple definition: Huber Loss combines the best of MSE and MAE. It’s strict on small errors but more tolerant on large errors (outliers).

Description: It’s like a teacher who is strict on small mistakes but understands that you can make big errors by accident.

Principle:

Small errors: MSE behavior (penalizes hard)
Large errors: MAE behavior (penalizes moderately)

Advantages:

Combines advantages of MSE and MAE
Robust to outliers while still penalizing small errors

When to use:

Outliers present but you still want to penalize them a bit
Compromise between MSE and MAE

Loss Functions for Classification

Binary Cross-Entropy (BCE)

Simple definition: BCE measures how wrong the model is when it must choose between two options (YES or NO, true or false). The more confident AND wrong the model is, the more enormous the penalty.

Description: Imagine a doctor who is 99% sure you’re sick, but you’re healthy - the error is catastrophic!

Principle: Measures the gap between predicted probability and true class (for 2 classes).

Characteristics:

Penalizes exponentially confident but wrong predictions

Intuitive example:

True label: YES (sick)
Prediction 90% YES → small penalty ✅
Prediction 10% YES → big penalty ❌
Prediction 1% YES → huge penalty ⚠️

When to use:

Binary classification (spam/not-spam, sick/healthy)
Network output = sigmoid

Categorical Cross-Entropy (CCE)

Simple definition: CCE is the version of BCE for choosing among multiple options (cat, dog, bird…). It penalizes the model if it’s confident on the wrong answer.

Description: It’s like a multiple-choice quiz where you lose more points if you’re very confident on the wrong answer.

Principle: Version of BCE for more than 2 classes.

Concrete example:

Classes: cat, dog, bird
True label: cat

Prediction: [0.7 cat, 0.2 dog, 0.1 bird]
→ Small loss (good! 70% confident on cat) ✅

Prediction: [0.1 cat, 0.8 dog, 0.1 bird]
→ Big loss (bad! confident on dog when it's a cat) ❌

When to use:

Multi-class classification (digits 0-9, types of animals)
Network output = softmax

Focal Loss - For Imbalanced Classes

Simple definition: Focal Loss is a smart version of Cross-Entropy that makes the model focus on difficult examples rather than wasting time on easy examples.

Description: It’s like a teacher who gives more attention to struggling students rather than those who already understand everything.

Principle: Improved version of Cross-Entropy that focuses on difficult examples.

How it works:

Easy examples (well predicted) → reduced penalty
Difficult examples (poorly predicted) → normal penalty

Effect: The model spends more time learning difficult cases.

When to use:

Very imbalanced classes (e.g., 1% fraud, 99% normal)
Object detection
Anomaly detection

Comparison Table of Loss Functions

Loss	Type	Outlier Robustness	Usage
MSE	Regression	❌ Low	Standard regression
MAE	Regression	✅ High	Regression with outliers
Huber	Regression	✅ Medium	Compromise
Binary Cross-Entropy	Classification	N/A	2 classes
Categorical Cross-Entropy	Classification	N/A	Multi-class
Focal Loss	Classification	N/A	Imbalanced classes

How to Choose Your Loss Function?

Simple decision tree:

Regression (predict a number)?
├─ Yes
│  ├─ Outliers present?
│  │  ├─ Yes → MAE or Huber
│  │  └─ No → MSE
│
└─ No (Classification)
   ├─ 2 classes? → Binary Cross-Entropy
   ├─ Balanced multi-class? → Categorical Cross-Entropy
   └─ Imbalanced classes? → Focal Loss

Evaluation Metrics

Difference: Loss vs Metrics

Loss Function:

What the model optimizes during training
Not always easy for a human to understand

Metrics:

What we use to evaluate performance
Easy to interpret and understand
Aligned with business objectives

Example: We train with Cross-Entropy (loss), but we evaluate with Accuracy (metric).

Metrics for Classification

The Confusion Matrix

To understand metrics, you must first understand 4 concepts:

                Model Prediction
                YES         NO
Reality  YES    TP          FN
         NO     FP          TN

Simple definitions:

TP (True Positive): model says YES, it’s really YES ✅
TN (True Negative): model says NO, it’s really NO ✅
FP (False Positive): model says YES, but it’s NO ❌ (false alarm)
FN (False Negative): model says NO, but it’s YES ❌ (missed case)

Example (Medical test):

TP: test says sick, patient really sick ✅
TN: test says healthy, patient really healthy ✅
FP: test says sick, patient healthy ❌ (false alarm, unnecessary panic)
FN: test says healthy, patient sick ❌ (DANGEROUS! Missed case)

Accuracy (Overall Precision)

Simple definition: Accuracy is the simplest metric: it’s the percentage of correct predictions. If you have 85% accuracy, it means the model is right 85 times out of 100.

Description: It’s like your grade on an exam: 85/100 = 85% success.

Detailed explanation: Percentage of correct predictions.

Calculation: Accuracy = (Correct predictions) / (Total predictions)

Example:

Out of 100 tests:
- 85 correct predictions
- 15 errors
Accuracy = 85/100 = 85%

Advantages:

Very simple to understand
Easy to explain

IMPORTANT TRAP: Doesn’t work well with imbalanced classes!

Example of the trap:

Dataset: 95% not-spam, 5% spam
Naive model that ALWAYS says "not-spam"
→ Accuracy = 95% (looks great!)
But: detects NO spam (useless!)

When to use:

Balanced classes (50/50 or close)
Both types of errors have the same importance

When to avoid:

Imbalanced classes
One type of error is more serious than the other

Precision

Simple definition: Precision measures: “When the model says YES, how often is it really right?” It’s important when false alarms are costly.

Description: Imagine a smoke detector that’s too sensitive and goes off all the time - it has bad precision (many false alarms).

Question asked: “When the model says YES, how often is it right?”

Calculation: Precision = True positives / All predicted positives

Concrete example (Spam detector):

Model marks 100 emails as spam
- 70 are really spam (TP)
- 30 are important (FP - ERROR!)

Precision = 70/100 = 70%

Interpretation: Out of 10 emails marked spam, 7 are really spam, but 3 are important.

High importance when: The cost of a false alarm is high

Examples:

Spam filter: marking an important email as spam → angry customer
Recommendations: recommending a bad product → frustrated user
Marketing targeting: targeting someone who won’t buy → unnecessary cost

Business interpretation: High precision = conservative model: “I only say YES if I’m very sure”

Recall (Sensitivity)

Simple definition: Recall measures: “Of the really positive cases, how many does the model detect?” It’s important when missing a case is dangerous.

Description: Imagine a smoke detector that never goes off - it has bad recall (misses real dangers).

Question asked: “Of the really positive cases, how many does the model find?”

Calculation: Recall = True positives / All real positives

Concrete example (Cancer detection):

100 patients really have cancer
- 90 are detected by the model (TP)
- 10 are NOT detected (FN - SERIOUS!)

Recall = 90/100 = 90%

Interpretation: The model detects 90% of cancers, but misses 10% (dangerous!).

High importance when: The cost of missing a case is high

Examples:

Cancer detection: missing a cancer → potentially fatal 🚨
Fraud detection: missing fraud → financial loss
Security: missing a danger → catastrophe
COVID: missing a case → disease spread

Business interpretation: High recall = liberal model: “I prefer to say YES too often than miss cases”

The Precision vs Recall Dilemma

Problem: Improving one often degrades the other!

Conservative model (high precision):

Says YES only if very sure
Few false alarms (high precision ✅)
But misses many cases (low recall ❌)

Liberal model (high recall):

Says YES at the slightest doubt
Detects almost all cases (high recall ✅)
But many false alarms (low precision ❌)

Example:

Very strict spam detector:
→ Precision = 95% (almost everything marked spam is really spam)
→ Recall = 50% (but misses half of the spam)

Very loose spam detector:
→ Precision = 40% (many false alarms)
→ Recall = 98% (catches almost all spam)

F1-Score - The Balance

Simple definition: F1-Score is a compromise between Precision and Recall. It’s an overall score that penalizes the model if either one is bad.

Description: It’s like a harmonic mean - to have a good F1, you MUST be good at Precision AND Recall, not just one of them.

Principle: Combines Precision and Recall into a single number.

Important characteristic: If Precision OR Recall is low, F1 will be low too.

Example:

Case 1:
Precision = 100%, Recall = 10%
F1 = 18% (low, because recall too low)

Case 2:
Precision = 50%, Recall = 50%
F1 = 50% (balance)

Case 3:
Precision = 90%, Recall = 80%
F1 = 85% (good balance)

When to use:

You want a compromise between Precision and Recall
Imbalanced classes
You want a single metric to compare models

AUC-ROC - Overall Performance

Simple definition: AUC-ROC is a score between 0 and 1 that measures the model’s overall ability to distinguish positive from negative, regardless of the decision threshold chosen.

Description: It’s like evaluating a student’s general ability, not just their grade on a single exam. A good model will have an AUC close to 1.

Principle: Measures model performance for all possible thresholds.

What is a threshold?

The model gives a probability: 0.7 (70% confident)
Threshold = 0.5: 0.7 > 0.5 → prediction YES
Threshold = 0.8: 0.7 < 0.8 → prediction NO

ROC Curve: Tests all possible thresholds and plots a curve.

AUC (Area Under Curve): Area under the ROC curve - value between 0 and 1.

Interpretation:

AUC = 1.0: perfect model 🏆
AUC = 0.9-1.0: excellent
AUC = 0.8-0.9: good
AUC = 0.7-0.8: acceptable
AUC = 0.5-0.7: weak
AUC = 0.5: as good as coin flip 🎲
AUC < 0.5: worse than random (reverse predictions!)

Advantages:

Evaluates the model globally (all thresholds)
No need to choose a threshold in advance
Facilitates comparison between models

When to use:

Compare multiple models
Imbalanced classes
You don’t yet know which threshold to use

Metrics for Regression

MAE (Mean Absolute Error)

Principle: Average error, in the unit of what you’re predicting.

Example (Price in dollars):

Predictions: [$100, $200, $150]
True values: [$110, $180, $155]
Errors: [$10, $20, $5]
MAE = (10 + 20 + 5) / 3 = $11.67

Simple interpretation: “On average, I’m off by $11.67”

Advantages:

Very easy to interpret
Same unit as what you’re predicting
Robust to outliers

RMSE (Root Mean Squared Error)

Principle: Similar to MAE but penalizes large errors more heavily.

Difference with MAE:

MAE: error of 10 → penalty of 10
RMSE: error of 10 → penalty closer to 10.5
Large error of 50 → RMSE penalizes much more

Advantages:

Same unit as what you’re predicting
Penalizes large errors more

Comparison MAE vs RMSE:

If RMSE » MAE: you have large errors (outliers)
If RMSE ≈ MAE: your errors are homogeneous

R² (R-squared / Coefficient of Determination)

Principle: Measures what percentage of variability is explained by the model.

Interpretation:

R² = 1: perfect model (100% of variance explained) 🏆
R² = 0.9: excellent (90% explained)
R² = 0.7: good
R² = 0.5: medium
R² = 0: model is as good as predicting the mean
R² < 0: model is WORSE than predicting the mean 😱

Intuitive example:

Predicting house prices
R² = 0.85

Interpretation:
85% of price variations are explained by characteristics
  (size, location, number of bedrooms...)
15% remain unexplained
  (luck, negotiation, market conditions...)

Advantages:

Easy to interpret (percentage)
Allows comparison between different datasets

Summary Table - Classification

Metric	Question	Use when
Accuracy	How many correct predictions?	Balanced classes
Precision	When I say YES, am I right?	False alarms costly
Recall	Of real YES, how many do I find?	Missed cases costly
F1-Score	What Precision/Recall balance?	Compromise needed
AUC-ROC	Overall performance all thresholds?	Compare models

Summary Table - Regression

Metric	Unit	Advantage	Use when
MAE	Same as y	Easy to interpret	Outliers present
RMSE	Same as y	Penalizes large errors	Large errors serious
R²	Unitless (%)	Intuitive	Compare datasets

Regularization - Fighting Overfitting

Understanding Overfitting

Analogy: A student who memorizes past exams by heart, but fails on new questions.

Signs of overfitting:

Train accuracy = 98%, Validation accuracy = 75% (large gap)
Train loss continues to decrease, validation loss goes back up
Excellent on training data, poor on new data

Regularization Techniques

1. Early Stopping - The Simplest

Simple definition: Early Stopping automatically stops training when the model starts to overfit. It’s the easiest and most effective regularization technique.

Description: It’s like a coach telling you “Stop, you’re at your best, if you continue you’ll overtrain and hurt yourself”.

Principle: Stops training when validation performance starts to degrade.

How it works:

Epochs 1-20: validation improves → continue
Epoch 25: best validation → save
Epochs 26-35: validation stagnates/degrades
Epoch 36: patience exhausted → STOP and restore epoch 25

Recommended configuration:

Patience: 10-15 epochs
Monitor: validation loss
Restore best weights: YES

Advantages:

Free (no additional computation)
Very effective
Saves time

2. Dropout - Powerful Technique

Simple definition: Dropout randomly deactivates neurons during training to force the network not to depend too much on specific neurons. This avoids overfitting.

Description: It’s like training a soccer team where in each game, some players are randomly absent - all players must become versatile.

Principle: During training, randomly deactivates neurons.

Why it’s effective:

Prevents co-dependency:

Neurons can’t count on their neighbors
Each neuron must learn useful things independently

Forces redundancy:

Important information must be encoded by multiple neurons
Makes the network more robust

Analogy: Training a team where each game, different players play. Everyone must be versatile.

Configuration:

Dropout = 0.2: 20% of neurons deactivated (light)
Dropout = 0.5: 50% deactivated (standard for large layers)

Where to place:

✅ After large layers (512+ neurons)
❌ Not on output layer
❌ Not on first layer

3. L2 Regularization (Weight Decay)

Simple definition: L2 Regularization penalizes weights that are too large in the network, forcing the model to find simpler and more general solutions.

Description: It’s like a diet for the network - we prevent it from becoming too “heavy” and complex by limiting weight size.

Principle: Penalizes weights that are too high, pushes the model toward simpler solutions.

Effect:

Weights are pushed toward zero (but not exactly zero)
The model becomes less “confident” and more cautious

Configuration:

Lambda = 0.01: moderate regularization (default)
Lambda = 0.001: light
Lambda = 0.1: strong

When to use:

Moderate to strong overfitting
Many features
Model with many parameters

4. Data Augmentation

Simple definition: Data Augmentation artificially creates new training data by slightly modifying existing data (rotation, zoom, etc.). More data = less overfitting.

Description: It’s like having 100 photos of a cat and creating 1000 photos by rotating them, zooming, changing brightness - the model sees more variations.

Principle: Artificially create new training data by transforming existing data.

For images:

Rotation (-20° to +20°)
Zoom
Horizontal flip
Brightness change
Contrast change

Example:

1 cat image
→ Rotation: 5 new images
→ Zoom: 3 new images
→ Flip: 1 new image
Total: 10 images from one!

For text:

Replace words with synonyms
Swap two words
Insert random words

When to use:

Small dataset (<10k images)
Image classification (very effective)
You want a robust model

Caution: Transformations must be realistic!

✅ Rotation of a face: OK
❌ Vertical flip of a face: weird

5. Batch Normalization

Simple definition: Batch Normalization normalizes data between each layer of the network to stabilize and accelerate learning. It’s like resetting the counters at each step.

Description: Imagine an assembly line where at each station, we check and adjust parts so they’re always in the right dimensions.

Principle: Normalizes activations between layers during training.

Multiple benefits:

Accelerates training (2-3× faster)
Regularizes (adds beneficial noise)
Allows using higher learning rates
Makes the network more stable

When to use:

Deep networks (>10 layers)
Computer vision (very common)
Unstable training
You want faster convergence

6. ReduceLROnPlateau

Simple definition: ReduceLROnPlateau automatically reduces the learning rate (learning speed) when the model stops progressing, allowing fine-tuning at the end of training.

Description: It’s like slowing down when you approach your destination - at first you drive fast, then you slow down to park precisely.

Principle: Automatically reduces learning rate when improvement stagnates.

Metaphor: At start: car (fast, exploration) Near goal: on foot (slow, precise)

Configuration:

Reduction: divide by 2
Patience: 5-10 epochs
Minimum learning rate: 0.0000001

Advantages:

Automatic
Avoids plateaus
Fine-tuning at end of training

Regularization Strategy by Levels

Level 1 - Light regularization:

Early stopping (patience 15-20)
Data augmentation (if images)
Light dropout (0.2-0.3)

Level 2 - Moderate regularization:

Stronger dropout (0.4-0.5)
L2 regularization (lambda=0.01)
ReduceLROnPlateau

Level 3 - Strong regularization:

Increase lambda (0.05-0.1)
Very strong dropout (0.6)
Collect more data

Principle: Add progressively, not all at once!

Training Methodology

Phase 1: Data Preparation

1. Exploration

Visualize data
Understand distribution
Identify anomalies

2. Cleaning

Handle missing values
Remove extreme outliers
Correct errors

3. Splitting

Train: 70-80% (to learn)
Validation: 10-15% (to adjust)
Test: 10-15% (for final evaluation)

4. Preprocessing

Normalization (put between 0 and 1)
Standardization (mean=0, std=1)
Encoding categorical variables

Phase 2: Baseline Model

Objective: Establish a simple reference

Actions:

Create a simple model: 1-2 layers, 64-128 neurons
No regularization (except early stopping)
Adam (lr=0.001), batch 32
Train 50-100 epochs

Evaluation:

Performance: is the problem feasible?
Train/val gap: overfitting already present?

Phase 3: Increase Complexity

When: Low performance on train AND validation (underfitting)

Progressive actions:

Double number of neurons (64 → 128)
Add 1-2 layers
Increase number of epochs
Add Batch Normalization

Check after each change:

Train accuracy increases? → good sign
Val accuracy follows? → excellent
Val accuracy stagnates/drops? → move to phase 4

Phase 4: Regularization

When: Large gap between train and validation (overfitting)

Apply by levels:

Increase early stopping patience
Add data augmentation
Add dropout (0.3-0.5)
Add L2 regularization
ReduceLROnPlateau

Phase 5: Fine-Tuning

When: Model performs well, you want the last %

Actions:

Test different learning rates
Test different batch sizes
Adjust dropouts
Try different optimizers

Best Practices

Recommended Workflow

1. Always start simple

Minimal viable model
No regularization at first
Establish baseline

2. Iterate methodically

One change at a time
Measure impact
Keep what works

3. Visualize constantly

Loss curves (train vs val)
Metric curves
Confusion matrix

4. Save smartly

Best model (minimal val loss)
Regular checkpoints

Checklist Before Training

Data explored and understood
Data cleaned
Train/val/test split done
Preprocessing defined
Architecture chosen
Hyperparameters defined
Early stopping configured
Metrics chosen

Checklist During Training

Monitor train vs val loss
Verify loss is decreasing
Observe stability
Save regularly

Checklist After Training

Evaluate on test set
Analyze errors
Calculate all metrics
Document results
Save final model

Common Mistakes to Avoid

1. Not separating train/val/test → Impossible to detect overfitting

2. Testing too often on validation → Overfitting on validation!

3. Forgetting to normalize → Very slow convergence

4. No early stopping → Waste of time and overfitting

5. Changing too many things at once → Impossible to know what works

6. Poorly chosen learning rate → #1 cause of failure!

7. Not visualizing → Misses obvious problems

8. Not analyzing errors → No targeted improvement

Quick Diagnosis

Problem: Loss becomes NaN Cause: Learning rate too high Solution: Divide learning rate by 10

Problem: No improvement after 20 epochs Cause: Learning rate too low Solution: Multiply by 2-5

Problem: Train accuracy = 100%, Val accuracy = 70% Cause: Severe overfitting Solution: Dropout + L2 + Data Augmentation

Problem: Train accuracy = 60%, Val accuracy = 58% Cause: Underfitting Solution: More complex model

Problem: All predictions = same class Cause: Imbalanced classes or LR too high Solution: Class weights + Reduce LR

Quick Start Guide

Recommended Default Configuration

Architecture:

2-3 hidden layers
128-256 neurons per layer
ReLU activation
Softmax or Sigmoid output

Training:

Optimizer: Adam
Learning rate: 0.001
Batch size: 32 (adjust based on memory)
Epochs: 100-200

Regularization:

Early stopping (patience 15)
Dropout 0.3-0.5

This configuration works for 80% of cases!

When to Change What

Low performance everywhere? → Increase complexity (+ layers, + neurons)

Large train/val gap? → More regularization (dropout, L2)

Unstable training? → Reduce learning rate, add Batch Norm

Training too slow? → Increase learning rate, increase batch size

Simple Glossary

Epoch: One complete pass over all training data

Batch: Group of examples processed together

Forward Pass: Data passes through the network

Backward Pass: Network calculates how to improve

Gradient: Direction to adjust weights

Learning Rate: Step size to adjust weights

Overfitting: Excessive memorization

Underfitting: Model too simple

Regularization: Techniques against overfitting

Deep Learning, Machine Learning

Deep Learning Machine Learning

This post is licensed under CC BY 4.0 by the author.
